Expert Swing Gate Installation & Automation

Swing gates offer several advantages: they require no track maintenance, work better on sloped driveways (sliding gates need level ground), are more cost-effective for wider openings, provide a classic elegant appearance, and can swing in or out based on your property layout. They're ideal when you have clearance space on one or both sides of the opening but limited space along the fence line where a sliding gate would travel.

You need enough clear arc space for the gate(s) to swing fully open, typically 90-120 degrees. For a single swing gate, this means the full width of your opening. For dual swing gates (two leaves meeting in the middle), each leaf swings half that distance. We recommend at least 12-15 feet of clear space from the gate's pivot point. During our site assessment, we'll measure your driveway and determine if swing gates are suitable or if modifications are needed.

Yes, absolutely! We install professional-grade swing gate operators from trusted brands like LiftMaster, Mighty Mule, FAAC, and Nice Apollo. Automation includes remote controls, wireless keypads, smartphone control via MyQ, intercom systems, and safety sensors. Operators can be solar-powered for off-grid locations or hardwired for maximum reliability. We also offer battery backup systems to ensure your gate works during power outages.

For Riverside's hot, dry climate, we recommend: Wrought Iron (powder-coated for rust protection) - classic, ornate, extremely durable; Steel (galvanized and powder-coated) - strong, customizable, excellent security; Aluminum - lightweight, rust-proof, low maintenance, modern aesthetic; Wood with metal frame - natural beauty, requires regular sealing. We typically advise against bare steel or untreated wood due to heat and occasional rain. Powder-coated metal gates perform best long-term in our climate.

Residential swing gate installation typically takes 2-4 days depending on complexity. Day 1: Site prep, post installation (set in concrete, must cure 24-48 hours). Day 2-3: Gate mounting, hardware installation, operator mounting and wiring. Day 4: Programming, safety sensor calibration, testing, and customer training. Rush service may be available. Commercial installations with more complex access control can take 5-7 days. We provide a detailed timeline before starting work.

Yes! This is actually one of swing gates' biggest advantages over sliding gates. Swing gates can be installed on sloped driveways because they don't require a level track. We adjust the gate angle and use specialized hinges to accommodate slopes. For steep inclines, we may recommend single swing gates that open uphill or dual gates with staggered mounting. During our assessment, we'll evaluate your driveway grade and recommend the best configuration.

All our automated swing gate installations include comprehensive safety systems: safety photo-eyes that stop/reverse the gate if something blocks its path, pressure sensors on the gate edges, auto-reverse if gate encounters resistance, manual emergency release (opens gate during power failure), adjustable force limits to prevent crushing, flashing warning lights during operation, and UL-325 compliant safety features required by law. Safety is our top priority.

Swing gate costs vary widely based on size, materials, and features. Basic manual single swing gates start around $2,500-$4,000. Automated single swing gates typically range $4,500-$8,000. Dual swing gates with full automation run $7,000-$15,000. Custom ornamental gates with smart access systems can reach $15,000-$30,000+. Factors affecting price: gate width, material (aluminum vs. wrought iron), automation level, access control features, and decorative elements. We offer free quotes after a site visit.
